IPV-18210800M410
IPV-18210800M410
Product Features
◆High efficiency:MBB technology is adopted to improve the photoelectric conversion efficiency and achieve higher power generation capacity.
◆Low resistance loss:The design of multiple current collection lines reduces the flow distance of the current inside the cell and reduces resistance loss.
◆High Reliability:By reducing the stress and thermal stress between cells, the reliability and long-term performance stability of the module are improved.
◆Beautiful appearance:Modules using MBB technology have a more detailed cell layout and less wire shielding, presenting a more beautiful appearance.
◆Adapt to complex environments:With good anti-PID performance and durable anti-reflection coating, it can work in different climates and environmental conditions, and has certain pressure and wind resistance.
Product Parameters
| Power | 410W | Solar Cell | 182 Mono |
| Module Efficiency | 21.00% | Solar Cells Number | 108Pcs(6*9*2) |
| Voltage at Pmax | 30.95V | Dimension | 1720*1134*35mm |
| Current at Pmax | 13.25A | Weight | 21.5KG/Pc |
| Open Circuit Voltage | 37.23V | Junction Box | IP68/3*bypass |
| Short Circuit Current | 14.00A | Cable | 4.0mm²/300mm |
| Power Tolerance | ±3% | Connector | MC4 |
Product Usage
◆Solar power plants:They can be used for the construction of large-scale solar power plants, generating electricity for the grid or large industrial users.
◆Commercial and industrial buildings: They are suitable for rooftop installations on commercial and industrial buildings, providing renewable power supply and reducing energy costs.
◆Agriculture and rural areas:They can be used in agricultural greenhouses, irrigation systems, and for lighting and power supply in rural areas, meeting the energy needs of agriculture and rural communities.
◆Remote areas and islands:Due to their high power output and adaptability to complex environments, they are suitable for providing power supply in remote areas and on islands, reducing reliance on traditional energy sources.
◆Mountainous regions and outdoor activities:They are suitable for outdoor activities in mountainous regions, such as camping, hiking, and outdoor music festivals, providing portable renewable energy solutions.
